Electrical faults can range from minor inconveniences—like flickering lights—to serious hazards such as electric shocks or fire risks. At NICEIC Electricians, our mission is to make your property electrically safe using trusted fault detection methods. Whether you’re experiencing circuit tripping, power loss, or strange burning smells, our electricians are trained to trace the source precisely and safely.
In this guide, we’ll walk you through the most common methods we use to detect faults, based on years of experience across London homes, offices, and commercial units.
1. Visual Inspection: The First Step
Before diving into testing, a thorough visual inspection is always conducted. This allows our engineers to quickly spot:
-
Burn marks around sockets or light fittings
-
Loose or exposed wiring
-
Overloaded distribution boards
-
Water damage or corrosion
While not every fault is visible, many issues—especially in older installations—can be spotted with a trained eye.
2. Continuity Testing: Checking Cable Integrity
Continuity testing ensures that electrical paths are complete and unbroken. Using a multimeter or continuity tester, we check:
A break in continuity can indicate a severed wire, faulty switch, or disconnected terminal.
3. Insulation Resistance Testing: Detecting Leaks
Over time, the insulation surrounding electrical wires can degrade due to age, heat, or moisture. Our team uses insulation resistance testers (meggers) to identify:
Readings are taken between conductors and between conductors and earth. Low resistance means electricity may be leaking where it shouldn’t.
4. Earth Loop Impedance Testing: Ensuring Quick Disconnection
This test ensures that the earth path is effective enough to allow a fuse or circuit breaker to trip in the event of a fault. It’s vital for:
-
Confirming that the earth system is safe
-
Preventing overheating of conductors
-
Meeting British Standard BS 7671
High loop impedance readings may indicate a poor or unsafe earth connection.
5. RCD Testing: Verifying Safety Devices
Residual Current Devices (RCDs) are life-saving components designed to cut off electricity if a leakage is detected. Our engineers simulate faults to verify:
-
That the RCD trips within milliseconds
-
That it activates at the correct leakage threshold
-
That it protects the required circuits
A non-functioning RCD is a major safety risk, especially in bathrooms and kitchens.
6. Thermal Imaging: Spotting Overheating Components
In commercial and high-load environments, we may use thermal imaging cameras to detect hot spots in:
-
Fuse boards
-
Distribution panels
-
Machinery connections
This non-invasive method helps locate overloaded circuits and failing components early—before a fault occurs.
7. Voltage Drop Testing: Assessing Supply Health
Excessive voltage drop can lead to inefficient appliance performance or even damage. We measure voltage at different points of the circuit to detect:
It’s particularly important for larger properties and commercial units.
8. Component Substitution: Isolating Faulty Devices
When testing points to a suspected device—such as a socket outlet, switch, or appliance—we sometimes use a substitution method. By removing the suspect component and replacing it with a known working unit, we can confirm if it’s faulty.
